Technical Specifications of PESD5V0S4UD,115
| Datasheet |  PESD5V0S4UD,115 datasheet |
|---|
| Product Photos | SC-74, SOT-457 |
|---|
| Product Training Modules | ESD Standards and Products |
|---|
| PCN Design/Specification | Resin Hardener 02/Jul/2013 |
|---|
| PCN Packaging | Lighter Reels 02/Jan/2014 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 3,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | 4 |
|---|
| Bidirectional Channels | - |
|---|
| Voltage - Reverse Standoff (Typ) | 5V (Max) |
|---|
| Voltage - Breakdown (Min) | 6.4V |
|---|
| Voltage - Clamping (Max) @ Ipp | 13V |
|---|
| Current - Peak Pulse (10/1000μs) | 20A (8/20μs) |
|---|
| Power - Peak Pulse | 200W |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | 165pF @ 1MHz |
|---|
| Operating Temperature | -65°C ~ 150°C (TA) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | SC-74, SOT-457 |
|---|
| Supplier Device Package | 6-TSOP |
|---|
| Online Catalog | PESDx Series |
|---|
| Other Names | 568-4267-2 934059302115 PESD5V0S4UD T/R |
|---|
We can supply NXP Semiconductors part# PESD5V0S4UD,115. Use the request quote form to request PESD5V0S4UD,115 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PESD5V0S4UD,115. The price and lead time for PESD5V0S4UD,115 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PESD5V0S4UD,115. We look forward to doing business with you.
