Technical Specifications of CPDQ5V0-HF
| Datasheet |  CPDQ5V0-HF datasheet |
|---|
| Product Photos | 0402 (1006 Metric) |
|---|
| Product Training Modules | Flat Chip DiodesESD and ESD Suppressors |
|---|
| RoHS Information | RoHS Declaration |
|---|
| PCN Packaging | Label D/C Chg 24/Mar/2016 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 8,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | - |
|---|
| Bidirectional Channels | 1 |
|---|
| Voltage - Reverse Standoff (Typ) | 5V |
|---|
| Voltage - Breakdown (Min) | 5.6V |
|---|
| Voltage - Clamping (Max) @ Ipp | 18.6V |
|---|
| Current - Peak Pulse (10/1000μs) | 9.4A (8/20μs) |
|---|
| Power - Peak Pulse | 174W |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | 15pF @ 1MHz |
|---|
| Operating Temperature | -40°C ~ 125°C (TA) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | SOD-923 |
|---|
| Supplier Device Package | 0402/SOD-923F |
|---|
| Online Catalog | CPD Series |
|---|
| Other Names | 641-1478-2 CPDQ5V0HF |
|---|
We can supply Comchip Technology part# CPDQ5V0-HF. Use the request quote form to request CPDQ5V0-HF pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CPDQ5V0-HF. The price and lead time for CPDQ5V0-HF depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CPDQ5V0-HF. We look forward to doing business with you.
