Technical Specifications of VBUS054B-HSF-GS08
| Datasheet |  VBUS054B-HSF-GS08 datasheet |
|---|
| Product Photos | 6-UDFN Exposed Pad |
|---|
| Product Training Modules | ESD Protection Family |
|---|
| Catalog Drawings | VBUS054B Series Schematic |
|---|
| Standard Package | 3,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Steering (Rail to Rail) |
|---|
| Unidirectional Channels | - |
|---|
| Bidirectional Channels | 4 |
|---|
| Voltage - Reverse Standoff (Typ) | 5V (Min) |
|---|
| Voltage - Breakdown (Min) | 6.9V |
|---|
| Voltage - Clamping (Max) @ Ipp | 15V |
|---|
| Current - Peak Pulse (10/1000μs) | 3A (8/20μs) |
|---|
| Power - Peak Pulse | 45W |
|---|
| Power Line Protection | Yes |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | - |
|---|
| Operating Temperature | -40°C ~ 125°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 6-UFDFN Exposed Pad |
|---|
| Supplier Device Package | LLP75-6L |
|---|
| Online Catalog | VBUS and VESD Series |
|---|
| Other Names | 751-1453-2 VBUS054B-HSF-GS08-ND VBUS054BHSFGS08 |
|---|
We can supply Vishay Semiconductor Diodes Division part# VBUS054B-HSF-GS08. Use the request quote form to request VBUS054B-HSF-GS08 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number VBUS054B-HSF-GS08. The price and lead time for VBUS054B-HSF-GS08 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# VBUS054B-HSF-GS08. We look forward to doing business with you.
