Technical Specifications of ESDH12VD1-TP
| Datasheet |  ESDH12VD1-TP datasheet |
|---|
| Product Photos | SOD-123 |
|---|
| Standard Package | 3,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | 1 |
|---|
| Bidirectional Channels | - |
|---|
| Voltage - Reverse Standoff (Typ) | 12V (Max) |
|---|
| Voltage - Breakdown (Min) | 13V |
|---|
| Voltage - Clamping (Max) @ Ipp | 35V |
|---|
| Current - Peak Pulse (10/1000μs) | 120A (8/20μs) |
|---|
| Power - Peak Pulse | 4200W (4.2kW) |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | 620pF @ 1MHz |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | SOD-123 |
|---|
| Supplier Device Package | SOD-123 |
|---|
| Online Catalog | ESD Series |
|---|
| Other Names | ESDH12VD1-TPMSTR |
|---|
We can supply Micro Commercial Co part# ESDH12VD1-TP. Use the request quote form to request ESDH12VD1-TP pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ESDH12VD1-TP. The price and lead time for ESDH12VD1-TP depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ESDH12VD1-TP. We look forward to doing business with you.
