Technical Specifications of VESD09A4A-HS4-GS08
| Datasheet |  VESD09A4A-HS4-GS08 datasheet |
|---|
| Catalog Drawings | VESD05, 09 Schematic |
|---|
| PCN Obsolescence/ EOL | EOL 21/Mar/2016 |
|---|
| Standard Package | 1 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | - |
|---|
| Packaging | Cut Tape (CT) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | 4 |
|---|
| Bidirectional Channels | - |
|---|
| Voltage - Reverse Standoff (Typ) | 9V (Max) |
|---|
| Voltage - Breakdown (Min) | 11.2V |
|---|
| Voltage - Clamping (Max) @ Ipp | 23V |
|---|
| Current - Peak Pulse (10/1000μs) | 1.5A (8/20μs) |
|---|
| Power - Peak Pulse | 30W |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | 6.2pF @ 1MHz |
|---|
| Operating Temperature | -40°C ~ 125°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 5-XFDFN Exposed Pad |
|---|
| Supplier Device Package | LLP1010-5L |
|---|
| Other Names | 751-1457-1 VESD09A4AHS4GS08 |
|---|
We can supply Vishay Semiconductor Diodes Division part# VESD09A4A-HS4-GS08. Use the request quote form to request VESD09A4A-HS4-GS08 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number VESD09A4A-HS4-GS08. The price and lead time for VESD09A4A-HS4-GS08 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# VESD09A4A-HS4-GS08. We look forward to doing business with you.
