Technical Specifications of SMAJ40A-13-F
| Datasheet |  SMAJ40A-13-F datasheet |
|---|
| Product Photos | DO-214AC, SMA (Unidirectional)SMA |
|---|
| RoHS Information | RoHS Cert of Compliance |
|---|
| PCN Assembly/Origin | Assembly Process Chg 11/Mar/2016 |
|---|
| EDA / CAD Models | Download from Accelerated Designs |
|---|
| Standard Package | 5,000 |
|---|
| Category | Circuit Protection |
|---|
| Family | TVS - Diodes |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Type | Zener |
|---|
| Unidirectional Channels | 1 |
|---|
| Bidirectional Channels | - |
|---|
| Voltage - Reverse Standoff (Typ) | 40V |
|---|
| Voltage - Breakdown (Min) | 44.4V |
|---|
| Voltage - Clamping (Max) @ Ipp | 64.5V |
|---|
| Current - Peak Pulse (10/1000μs) | 6.2A |
|---|
| Power - Peak Pulse | 400W |
|---|
| Power Line Protection | No |
|---|
| Applications | General Purpose |
|---|
| Capacitance @ Frequency | - |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | DO-214AC, SMA |
|---|
| Supplier Device Package | SMA |
|---|
| Online Catalog | SMAJ Series |
|---|
| Other Names | SMAJ40A-FDITR SMAJ40A13F |
|---|
We can supply Diodes Incorporated part# SMAJ40A-13-F. Use the request quote form to request SMAJ40A-13-F pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SMAJ40A-13-F. The price and lead time for SMAJ40A-13-F depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SMAJ40A-13-F. We look forward to doing business with you.
