PCN10C-20S-2.54DSA(72)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | PCN10C-20S-2.54DSA(72) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | CONN DIN RECEPT 20POS DUAL STR |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| PCN10C-20S-2.54DSA(72) Price |  |
Technical Specifications of PCN10C-20S-2.54DSA(72)
| Datasheet |  PCN10C-20S-2.54DSA(72) datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - DIN 41612 |
| Manufacturer | Hirose Electric Co Ltd |
| Series | PCN10 |
| Packaging | Tray |
| Part Status | Active |
| Connector Type | Receptacle, Female Sockets |
| Number of Positions | 20 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Style | - |
| Level, Class | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 8μin (0.20μm) |
| Operating Temperature | -55°C ~ 85°C |
| Current Rating | 2A |
| Material Flammability Rating | UL94 V-0 |
| Material - Insulation | Polybutylene Terephthalate (PBT) |
