106015-1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 106015-1 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | CONN HEADER R/A 110 POS 2MM PCB |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 106015-1 Price |  |
Technical Specifications of 106015-1
| Datasheet |  106015-1 datasheet |
|---|---|
| Product Photos | 106015-1 |
| RoHS Information | 106015-1 Statement of Compliance |
| 3D Model | 106015-1.pdf |
| Standard Package | 11 |
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - Hard Metric, Standard |
| Series | Z-PACK |
| Packaging | Tube |
| Connector Type | Header, Male Pins |
| Connector Style | A 22 |
| Number of Positions | 110 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 5 |
| Mounting Type | Through Hole, Right Angle |
| Termination | Press-Fit |
| Connector Usage | Backplane |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Current Rating | - |
| Voltage Rating | - |
| Operating Temperature | - |
| Features | - |
| Mating Products | A114643-ND - CONN RCPT 110POS RTANG GOLD 2MM |
