HM2P09PDP130N9
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HM2P09PDP130N9 |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | CONN HEADER 55POS TYPE C VERT |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| HM2P09PDP130N9 Price |  |
Technical Specifications of HM2P09PDP130N9
| Datasheet |  HM2P09PDP130N9 datasheet |
|---|---|
| PCN Obsolescence/ EOL | Millipacs Header & Receptacle 13/Feb/2014 |
| PCN Design/Specification | Millipacs Design 15/Sept/2010HM2P, HM2J Plating 20/Oct/2011HM2 Series Copper Alloy 22/Jun/2013 |
| PCN Packaging | Millipacs UL/CSA marking 01/July/2009Millipacs Devices 16/Dec/2010 |
| Standard Package | 96 |
| Category | Connectors, Interconnects |
| Family | Backplane Connectors - Hard Metric, Standard |
| Series | Millipacs? |
| Packaging | Tray |
| Connector Type | Header, Male Pins |
| Connector Style | C 11 |
| Number of Positions | 55 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 5 |
| Mounting Type | Through Hole |
| Termination | Press-Fit |
| Connector Usage | CompactPCI |
| Contact Finish | Gold |
| Contact Finish Thickness | Flash |
| Current Rating | 1.5A |
| Voltage Rating | 750V |
| Operating Temperature | -55°C ~ 125°C |
| Features | Board Guide |
| Mating Products | HM2R03PA5100N9-ND - CONN RECEPT 55POS TYPE C R/A |
