Technical Specifications of DL2-96RW-4B
| Datasheet |  DL2-96RW-4B datasheet |
|---|
| Product Photos | DL2-96RW-4B |
|---|
| Featured Product | DL Series (ZIF) Connectors |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Backplane Connectors - Specialized |
|---|
| Series | DL |
|---|
| Packaging | Bulk |
|---|
| Connector Usage | - |
|---|
| Connector Type | Receptacle, Hermaphroditic Contacts |
|---|
| Connector Style | - |
|---|
| Number of Positions | 96 |
|---|
| Number of Positions Loaded | All |
|---|
| Pitch | 0.100" (2.54mm) |
|---|
| Number of Rows | 8 |
|---|
| Number of Columns | - |
|---|
| Mounting Type | Panel Mount |
|---|
| Termination | Wire Wrap |
|---|
| Contact Layout, Typical | - |
|---|
| Features | Actuating Camshaft Socket, Zero Insertion Force (ZIF) |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Color | Black |
|---|
| Current Rating | - |
|---|
| Material Flammability Rating | UL94 V-1 |
|---|
| Operating Temperature | -55°C ~ 105°C |
|---|
| Voltage Rating | - |
|---|
| Online Catalog | DL Series |
|---|
| Mating Products | 1003-1639-ND - CONN 96POS ZIF PCB PLUG |
|---|
| Associated Product | 1003-1675-ND - DL2-96R COVER |
|---|
| Other Names | 1003-1640 110855-0013 DL296RW4B |
|---|
We can supply ITT Cannon, LLC part# DL2-96RW-4B. Use the request quote form to request DL2-96RW-4B pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number DL2-96RW-4B. The price and lead time for DL2-96RW-4B depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# DL2-96RW-4B. We look forward to doing business with you.
