Technical Specifications of MP2-HP10-51P1-KR
| Datasheet |  MP2-HP10-51P1-KR datasheet |
|---|
| Product Photos | MP2-HP10-51P1-KR |
|---|
| Catalog Drawings | MP2-HP Series |
|---|
| 3D Model | MP2-HP10-51P1-XXXX.stpMP2-HP10-51P1-XXXX.igsMP2-HP10-51P1-XXXX.x_t |
|---|
| Standard Package | 840 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Backplane Connectors - Specialized |
|---|
| Series | MetPak? MP2 |
|---|
| Packaging | Tube |
|---|
| Connector Usage | Backplane |
|---|
| Connector Type | Header, Male Blades |
|---|
| Connector Style | Blade Power |
|---|
| Number of Positions | 10 |
|---|
| Number of Positions Loaded | All |
|---|
| Pitch | 0.236" (6.00mm) |
|---|
| Number of Rows | 5 |
|---|
| Number of Columns | - |
|---|
| Mounting Type | Through Hole |
|---|
| Termination | Press-Fit |
|---|
| Contact Layout, Typical | 10 Power |
|---|
| Features | - |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Color | Beige |
|---|
| Current Rating | - |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Voltage Rating | - |
|---|
| Online Catalog | MetPak? MP2 Series |
|---|
| Mating Products | 3M5491-ND - CONN POWER SOCKET 5ROW 10POS SLD MP2-SP10-51M1-TR30-ND - CONN PWR SOCKET 2-FB 10POS 5ROW MP2-SP10-51M1-TR40B-ND - CONN PWR SOCKET 2-FB 10POS 5ROW MP2-SP10-51P1-TG30-ND - CONN PWR SOCKET 2-FB 10POS 5ROW MP2-SP10-51P1-TR30-ND - CONN PWR SOCKET 2-FB 10POS 5ROW |
|---|
| Other Names | 3M5498 5111176285 51111762851 70010001975 MP2HP1051P1KR |
|---|
We can supply 3M part# MP2-HP10-51P1-KR. Use the request quote form to request MP2-HP10-51P1-KR pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MP2-HP10-51P1-KR. The price and lead time for MP2-HP10-51P1-KR depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MP2-HP10-51P1-KR. We look forward to doing business with you.
