Technical Specifications of 0761505024
| Datasheet |  0761505024 datasheet |
|---|
| 3D Model | 0761505024 .pdf |
|---|
| PCN Design/Specification | Multiple Component Changes 12/Dec/2013Various Devices Identification 20/Apr/2015 |
|---|
| Standard Package | 84 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Backplane Connectors - Specialized |
|---|
| Series | Impact? 76150 |
|---|
| Packaging | Tray |
|---|
| Connector Usage | - |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Connector Style | Impact?, Guide Right |
|---|
| Number of Positions | 252 |
|---|
| Number of Positions Loaded | All |
|---|
| Pitch | 0.053" (1.35mm) |
|---|
| Number of Rows | 18 |
|---|
| Number of Columns | 14 |
|---|
| Mounting Type | Board Edge, Through Hole, Right Angle |
|---|
| Termination | Press-Fit |
|---|
| Contact Layout, Typical | 84 Differential Pairs |
|---|
| Features | - |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Color | Black |
|---|
| Current Rating | - |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Operating Temperature | -55°C ~ 85°C |
|---|
| Voltage Rating | 30V |
|---|
| Other Names | 0761-50-5024 761-50-5024 76150-5024 761505024 |
|---|
We can supply Molex, LLC part# 0761505024. Use the request quote form to request 0761505024 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 0761505024. The price and lead time for 0761505024 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 0761505024. We look forward to doing business with you.
