Technical Specifications of PJ-013C
| Product Photos | PJ-013C |
|---|
| RoHS Information | PJ-013C Cert of Compliance |
|---|
| Catalog Drawings | PJ-013,018,031 Schematic |
|---|
| 3D Model | PJ-013C |
|---|
| Standard Package | 500 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Barrel - Power Connectors |
|---|
| Series | - |
|---|
| Connector Type | Jack |
|---|
| Gender | Male |
|---|
| Plug/Mating Plug Diameter | 1.1mm ID, 3.5mm OD |
|---|
| Number of Positions/Contacts | 2 Conductors, 3 Contacts |
|---|
| Internal Switch(s) | Single Switch, Normally Closed |
|---|
| Mounting Type | Through Hole, Right Angle |
|---|
| Termination | Solder |
|---|
| Shielding | Unshielded |
|---|
| Features | Board Guide |
|---|
| Color | Black |
|---|
| Voltage - Rated | 24VDC |
|---|
| Current Rating | 3.5A |
|---|
| Contact Material | Copper |
|---|
| Contact Material - Plating | Nickel |
|---|
| Housing Color | Black |
|---|
| Housing Material | Thermoplastic |
|---|
| Operating Temperature | -25°C ~ 85°C |
|---|
| Other Names | CP-013C PJ-013C-ND |
|---|
We can supply CUI Inc. part# PJ-013C. Use the request quote form to request PJ-013C pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PJ-013C. The price and lead time for PJ-013C depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PJ-013C. We look forward to doing business with you.
