1473151-1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1473151-1 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | CARD EDGE 35 DUAL POS. |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 1473151-1 Price |  |
Technical Specifications of 1473151-1
| Datasheet |  1473151-1 datasheet |
|---|---|
| Product Photos | 1473151-1 |
| RoHS Information | 1473151-1 Statement of ComplianceRoHS 2 Statement |
| Standard Package | 16 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | - |
| Packaging | Tray |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | - |
| Number of Positions | 70 |
| Card Thickness | 0.054" ~ 0.070" (1.37mm ~ 1.78mm) |
| Number of Rows | 2 |
| Pitch | 0.100" (2.54mm) |
| Features | - |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Contact Finish Thickness | - |
| Contact Type | - |
| Color | - |
| Flange Feature | Flush Mount, Top Opening, Unthreaded, 0.130" (3.30mm) Dia |
| Operating Temperature | -20°C ~ 80°C |
| Material - Insulation | Thermoplastic |
| Read Out | Dual |
