MEC1-160-02-S-D-A
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MEC1-160-02-S-D-A |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | CONN EDGE CARD DL 1MM 120POS SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MEC1-160-02-S-D-A Price |  |
Technical Specifications of MEC1-160-02-S-D-A
| Datasheet |  MEC1-160-02-S-D-A datasheet |
|---|---|
| Product Photos | MEC1-120 SERIES |
| Catalog Drawings | MEC1 Series |
| Standard Package | 1 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | MEC1 |
| Packaging | Tube |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | - |
| Number of Positions | 120 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 2 |
| Pitch | 0.039" (1.00mm) |
| Features | Board Guide |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Contact Type | Loop Bellows |
| Color | Black |
| Flange Feature | - |
| Operating Temperature | -55°C ~ 125°C |
| Material - Insulation | Liquid Crystal Polymer (LCP) |
| Read Out | Dual |
| Online Catalog | MEC1 Series |
| Other Names | MEC116002SDA SAM8121 |
