EB41-S0C5040X
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | EB41-S0C5040X |
|---|---|
| Manufacturer | Vishay Dale |
| Description | CONN EDGEBOARD DUAL 100POS 3A |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| EB41-S0C5040X Price |  |
Technical Specifications of EB41-S0C5040X
| Datasheet |  EB41-S0C5040X datasheet |
|---|---|
| Standard Package | 1 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | EB4 |
| Packaging | Bulk |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | 50 |
| Number of Positions | 100 |
| Card Thickness | 0.054" ~ 0.071" (1.37mm ~ 1.80mm) |
| Number of Rows | 2 |
| Pitch | 0.100" (2.54mm) |
| Features | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | - |
| Contact Type | Cantilever |
| Color | Green |
| Flange Feature | Top Mount Opening, Unthreaded, 0.125" (3.18mm) Dia |
| Operating Temperature | -65°C ~ 125°C |
| Material - Insulation | Diallyl Phthalate (DAP) |
| Read Out | Dual |
| Other Names | EB41-C50SGFX T02 |
