RCC28DCAT
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Manufacturer Part Number | RCC28DCAT |
---|---|
Manufacturer | Sullins Connector Solutions |
Description | CONN EDGECARD 56POS R/A .100 SLD |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
RCC28DCAT Price |
Technical Specifications of RCC28DCAT
Datasheet | RCC28DCAT datasheet |
---|---|
Standard Package | 1 |
Category | Connectors, Interconnects |
Family | Card Edge Connectors - Edgeboard Connectors |
Series | - |
Packaging | Tube |
Card Type | Non Specified - Dual Edge |
Gender | Female |
Number of Positions/Bay/Row | 28 |
Number of Positions | 56 |
Card Thickness | 0.062" (1.57mm) |
Number of Rows | 2 |
Pitch | 0.100" (2.54mm) |
Features | - |
Mounting Type | Through Hole, Right Angle |
Termination | Solder |
Contact Material | Phosphor Bronze |
Contact Finish | Gold |
Contact Finish Thickness | 30μin (0.76μm) |
Contact Type | Hairpin Bellows |
Color | Green |
Flange Feature | Flush Mount, Top Opening, Threaded Insert, 4-40 |
Operating Temperature | -65°C ~ 125°C |
Material - Insulation | Polyphenylene Sulfide (PPS) |
Read Out | Dual |
