HSEC8-150-01-SM-DV-A
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HSEC8-150-01-SM-DV-A |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | CONN EDGE CARD DUAL .8MM 100POS |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| HSEC8-150-01-SM-DV-A Price |  |
Technical Specifications of HSEC8-150-01-SM-DV-A
| Datasheet |  HSEC8-150-01-SM-DV-A datasheet |
|---|---|
| Product Photos | HSEC8-150-01-SM-DV-A |
| Catalog Drawings | HSEC8 Series |
| Standard Package | 1 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | Edge Rate? HSEC8 |
| Packaging | Tube |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | 50 |
| Number of Positions | 100 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 2 |
| Pitch | 0.031" (0.80mm) |
| Features | Board Guide |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Contact Type | - |
| Color | Black |
| Flange Feature | - |
| Operating Temperature | -55°C ~ 125°C |
| Material - Insulation | Liquid Crystal Polymer (LCP) |
| Read Out | Dual |
| Online Catalog | Edge Rate? HSEC8 Series |
| Other Names | HSEC815001SMDVA SAM8083 |
