ABC50DKAI-S1191
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
Manufacturer Part Number | ABC50DKAI-S1191 |
---|---|
Manufacturer | Sullins Connector Solutions |
Description | CONN EDGECARD 100POS .100" |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
ABC50DKAI-S1191 Price |
Technical Specifications of ABC50DKAI-S1191
Datasheet | ABC50DKAI-S1191 datasheet |
---|---|
Standard Package | 1 |
Category | Connectors, Interconnects |
Family | Card Edge Connectors - Edgeboard Connectors |
Series | - |
Packaging | Tray |
Card Type | Non Specified - Dual Edge |
Gender | Female |
Number of Positions/Bay/Row | 50 |
Number of Positions | 100 |
Card Thickness | 0.093" (2.36mm) |
Number of Rows | 2 |
Pitch | 0.100" (2.54mm) |
Features | - |
Mounting Type | Through Hole, Right Angle |
Termination | Solder |
Contact Material | Beryllium Copper |
Contact Finish | Gold |
Contact Finish Thickness | 10μin (0.25μm) |
Contact Type | Cantilever |
Color | - |
Flange Feature | Top Mount Opening, Threaded Insert, 4-40 |
Operating Temperature | -65°C ~ 150°C |
Material - Insulation | Polyphenylene Sulfide (PPS) |
Read Out | Dual |
