GCC13DREN-S93
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | GCC13DREN-S93 |
|---|---|
| Manufacturer | Sullins Connector Solutions |
| Description | CONN EDGECARD 26POS .100 EYELET |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| GCC13DREN-S93 Price |  |
Technical Specifications of GCC13DREN-S93
| Datasheet |  GCC13DREN-S93 datasheet |
|---|---|
| Standard Package | 1 |
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | - |
| Packaging | Tray |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | 13 |
| Number of Positions | 26 |
| Card Thickness | 0.093" (2.36mm) |
| Number of Rows | 2 |
| Pitch | 0.100" (2.54mm) |
| Features | - |
| Mounting Type | Free Hanging (In-Line) |
| Termination | Solder Eyelet(s) |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Contact Type | Full Bellows |
| Color | Black |
| Flange Feature | - |
| Operating Temperature | -65°C ~ 125°C |
| Material - Insulation | Polyamide (PA9T), Nylon 9T |
| Read Out | Dual |
