C8D10PF29013
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | C8D10PF29013 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | CARD EDGE |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| C8D10PF29013 Price |  |
Technical Specifications of C8D10PF29013
| Standard Package | 500 |
|---|---|
| Category | Connectors, Interconnects |
| Family | Card Edge Connectors - Edgeboard Connectors |
| Series | - |
| Packaging | Bulk |
| Card Type | Non Specified - Dual Edge |
| Gender | Female |
| Number of Positions/Bay/Row | - |
| Number of Positions | 20 |
| Card Thickness | 0.062" (1.57mm) |
| Number of Rows | 2 |
| Pitch | 0.100" (2.54mm) |
| Features | - |
| Mounting Type | Through Hole |
| Termination | Press-Fit |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Contact Type | Cantilever |
| Color | Black |
| Flange Feature | - |
| Operating Temperature | -55°C ~ 125°C |
| Material - Insulation | Thermoplastic, Glass Filled |
| Read Out | Dual |
| Other Names | 2-1437260-0 |
