CIRH03T36A22SCNF80M32V0
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | CIRH03T36A22SCNF80M32V0 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | 22 Position Circular Connector Receptacle for Female Contacts Panel Mount, Flange Shielded |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| CIRH03T36A22SCNF80M32V0 Price |  |
Technical Specifications of CIRH03T36A22SCNF80M32V0
| Datasheet |  CIRH03T36A22SCNF80M32V0 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Circular Connectors - Housings |
| Manufacturer | TE-Connectivity-AMP-Connectors |
| Series | CIRH |
| Packaging | Bulk |
| Connector Type | Receptacle for Female Contacts |
| Number of Positions | 22 |
| Shell Size - Insert | 36-A22 |
| Shell Size, MIL | - |
| Contact Type | Crimp |
| Contact Size | 12 |
| Mounting Type | Panel Mount, Flange |
| Fastening Type | Bayonet Lock |
| Orientation | N (Normal) |
| Shell Material, Finish | Aluminum Alloy, Black Zinc Cobalt Plated |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Features | Shielded |
| Note | Contacts Not Provided |
