Technical Specifications of KPT2E16-23PEW
| Datasheet |  KPT2E16-23PEW datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPT |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 23 |
|---|
| Shell Size - Insert | 16-23 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange; Through Hole |
|---|
| Termination | Solder |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | - |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A, 13A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPT06J16-23S-ND - CONN PLUG 23POS W/SKT INLINE KPT08P16-23S-ND - CONN PLUG 23POS INLINE W/SKTS KPT06P16-23S-ND - CONN PLUG 23POS INLINE SKT IKPT06E16-23S-ND - CONN PLUG 23POS INLINE W/SKT IKPT06E16-23SDN-ND - CONN PLUG 23POS W/SKT INLINE IKPT06F16-23S-ND - CONN PLUG 23POS INLINE W/SKT IKPT08E16-23S-ND - CONN PLUG 23POS W/SKT INLINE R/A KPSE06E16-23S-ND - CONN PLUG 23POS INLINE SKT KPSE06F16-23S-ND - CONN PLUG 23POS INLINE SKT KPSE08E16-23S-ND - CONN PLUG 23POS INLINE RA SKT KPSE08F16-23S-ND - CONN PLUG 23POS INLINE RA SKT KPSE6E16-23SDN-ND - CONN PLUG 23POS INLINE SKT KPT08F16-23S-ND - CONN PLUG 23POS INLINE RA SKT KPT6E16-23SDN-ND - CONN PLUG 23POS INLINE SKT |
|---|
| Other Names | KPT2E1623PEW |
|---|
We can supply ITT Cannon, LLC part# KPT2E16-23PEW. Use the request quote form to request KPT2E16-23PEW pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPT2E16-23PEW. The price and lead time for KPT2E16-23PEW depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPT2E16-23PEW. We look forward to doing business with you.
