Technical Specifications of MS3116F16-8S
| Datasheet |  MS3116F16-8S datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | Military, MIL-DTL-26482 Series I, KPT |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Female Sockets |
|---|
| Number of Positions | 8 |
|---|
| Shell Size - Insert | 16-8 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 13A |
|---|
| Voltage - Rated | 1000VAC, 1400VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IMS3112E16-8P-ND - CONN RCPT 8POS BOX MNT W/PINS IMS3111F16-8P-ND - CONN RCPT 8POS CBL MNT W/PINS IMS3114E16-8P-ND - CONN RCPT 8POS JAM NUT W/PINS IMS3124E16-8P-ND - CONN RCPT 8POS JAM NUT W/PINS IMS3114F16-8P-ND - CONN RCPT 8POS JAM NUT W/PINS IMS3111J16-8P-ND - CONN RCPT 8POS CBL MNT W/PINS IMS3114P16-8P-ND - CONN RCPT 8POS JAM NUT W/PINS IMS3111E16-8P-ND - CONN RCPT 8POS CBL MNT W/PINS |
|---|
| Other Names | IMS3116F16-8S MS3116F16-8SPEI MS3116F16-8SPEI-ND |
|---|
We can supply ITT Cannon, LLC part# MS3116F16-8S. Use the request quote form to request MS3116F16-8S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MS3116F16-8S. The price and lead time for MS3116F16-8S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MS3116F16-8S. We look forward to doing business with you.
