Technical Specifications of CA3106F20-15PBF80
| Datasheet |  CA3106F20-15PBF80 datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-5015, CA-B |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Male Pins |
|---|
| Number of Positions | 7 |
|---|
| Shell Size - Insert | 20-15 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Reverse Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | IP67 - Dust Tight, Waterproof |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Silver |
|---|
| Features | - |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | 41A |
|---|
| Voltage - Rated | 50V |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | CA3102E20-15SB-ND - CONN RCPT 7POS BOX MNT W/SKTS CA3102E20-15SB05-ND - CONN RCPT 7POS BOX MNT W/SKTS CA3102E20-15SB111-ND - CONN RCPT 7POS BOX MNT W/SKTS CA3102E20-15SBF80-ND - CONN RCPT 7POS BOX MNT W/SKTS CA3102E20-15SBF80-05-ND - CONN RCPT 7POS BOX MNT W/SKTS CA3102E20-15SB04-ND - CONN RCPT 7POS BOX MNT W/SKTS CA3102E20-15SB109-ND - CONN RCPT 7POS BOX MNT W/SKTS CA3100E20-15SB02-ND - CONN RCPT 7POS WALL MNT W/SKTS CA3100E20-15SB-ND - CONN RCPT 7POS WALL MNT W/SKTS CA3100E20-15SB05-ND - CONN RCPT 7POS WALL MNT W/SKTS CA3100E20-15SB09-ND - CONN RCPT 7POS WALL MNT W/SKTS CA3100E20-15SBF80-ND - CONN RCPT 7POS WALL MNT W/SKTS CA3100R20-15SB-ND - CONN RCPT 7POS WALL MNT W/SKTS CA3100R20-15SBF80-05-ND - CONN RCPT 7POS WALL MNT W/SKTS CA3101E20-15SB-ND - CONN RCPT 7POS INLINE W/SKTS CA3101E20-15SBF80-ND - CONN RCPT 7POS INLINE W/SKTS CA3101F20-15SB-ND - CONN RCPT 7POS INLINE W/SKTS CA3101F20-15SBF80-ND - CONN RCPT 7POS INLINE W/SKTS CA07A20-15SB-ND - CONN RCPT 7POS JAM NUT W/SKTS CA07A20-15SB01-ND - CONN RCPT 7POS JAM NUT W/SKTS CA07A20-15SBF80-ND - CONN RCPT 7POS JAM NUT W/SKTS CA3102E20-15SB01-ND - CONN RCPT 7POS BOX MNT W/SKTS CA3102R20-15SB-ND - CONN RCPT 7POS BOX MNT W/SKTS |
|---|
We can supply ITT Cannon, LLC part# CA3106F20-15PBF80. Use the request quote form to request CA3106F20-15PBF80 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CA3106F20-15PBF80. The price and lead time for CA3106F20-15PBF80 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CA3106F20-15PBF80. We look forward to doing business with you.
