Technical Specifications of KPT06E16-23S
| Datasheet |  KPT06E16-23S datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPT |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Female Sockets |
|---|
| Number of Positions | 23 |
|---|
| Shell Size - Insert | 16-23 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | - |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A, 13A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPT02E16-23P-ND - CONN RCPT 23POS BOX W/PIN IKPT01J16-23P-ND - CONN RCPT 23POS W/PIN INLINE IKPT01F16-23P-ND - CONN RCPT 23POS W/PIN INLINE KPT00F16-23P-ND - CONN RCPT 23POS WALL MNT PIN IKPT01E16-23PDN-ND - CONN RCPT 23POS W/PIN INLINE IKPT07E16-23P-ND - CONN RCPT 23POS JAM NUT W/PIN IKPT07F16-23P-ND - CONN RCPT 23POS W/PIN JAM NUT IKPT01E16-23P-ND - CONN RCPT 23POS INLINE W/PIN KPSE02E16-23P-ND - CONN RCPT 23POS BOX MNT PIN KPSE07E16-23P-ND - CONN RCPT 23POS JAM NUT PIN KPSE0E16-23PDN-ND - CONN RCPT 23POS WALL MNT PIN KPSE1E16-23PDN-ND - CONN RCPT 23POS CBL MNT PIN KPSE7E16-23PDN-ND - CONN RCPT 23POS JAM NUT PIN KPT2E16-23PEW-ND - CONN RCPT 23POS BOX MNT PIN |
|---|
| Other Names | IKPT06E16-23S KPT06E1623S |
|---|
We can supply ITT Cannon, LLC part# KPT06E16-23S. Use the request quote form to request KPT06E16-23S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPT06E16-23S. The price and lead time for KPT06E16-23S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPT06E16-23S. We look forward to doing business with you.
