Technical Specifications of CA3102E22-23SBF80-05
| Datasheet |  CA3102E22-23SBF80-05 datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-5015, CA-B |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 8 |
|---|
| Shell Size - Insert | 22-23 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Reverse Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | IP67 - Dust Tight, Waterproof |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Silver |
|---|
| Features | - |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | 41A |
|---|
| Voltage - Rated | 50V |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | ICA3106E22-23PBF80F0-ND - CONN HSG INLINE MNT PLUG 8POS ICA3106E22-23PB-ND - CONN PLUG 8POS INLINE W/PINS ICA3106E22-23PB02-ND - CONN PLUG 8POS INLINE W/PINS ICA3106E22-23PBF80-ND - CONN PLUG 8POS INLINE W/PINS CA3108E22-23PB-ND - CONN PLUG 8POS INLINE W/PINS ICA06EW22-23PB02-ND - CONN PLUG 8POS INLINE W/PINS ICA06PG22-23PBF80-ND - CONN PLUG 8POS INLINE W/PINS ICA3108F22-23PBF80-ND - CONN PLUG 8POS RT ANG W/PINS ICA3106F22-23PB-ND - CONN PLUG 8POS INLINE W/PINS ICA3106F22-23PBF80-ND - CONN PLUG 8POS INLINE W/PINS |
|---|
| Other Names | CA3102E2223SBF8005 ICA3102E22-23SBF80-05 |
|---|
We can supply ITT Cannon, LLC part# CA3102E22-23SBF80-05. Use the request quote form to request CA3102E22-23SBF80-05 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CA3102E22-23SBF80-05. The price and lead time for CA3102E22-23SBF80-05 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CA3102E22-23SBF80-05. We look forward to doing business with you.
