Technical Specifications of KPT00E20-41SDN
| Datasheet |  KPT00E20-41SDN datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPT |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 41 |
|---|
| Shell Size - Insert | 20-41 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Shrink Boot Adapter |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPSE06F20-41PF0-ND - CONN HSG INLINE MNT PLUG 41POS IKPT06F20-41P-ND - CONN PLUG 41POS INLINE W/PIN IKPT06E20-41PDN-ND - CONN PLUG 41POS W/PIN INLINE IKPT06E20-41P-ND - CONN PLUG 41POS INLINE W/PIN IKPSE06F20-41P-ND - CONN PLUG 41POS CBL MNT W/PINS IKPSE6E20-41PDN-ND - CONN PLUG 41POS CBL MNT W/PINS IKPSE06E20-41PDN-ND - CONN PLUG 41POS CBL MNT W/PINS IKPSE06E20-41P-ND - CONN PLUG 41POS CBL MNT W/PINS IKPT06P20-41P-ND - CONN PLUG 41POS INLINE W/PIN IKPSE08P20-41P-ND - CONN PLUG 41POS CBL MNT W/PINS IKPT06J20-41P-ND - CONN PLUG 41POS INLINE W/PIN IKPSE06J20-41P-ND - CONN PLUG 41POS CBL MNT W/PINS KPSE08E20-41P-ND - CONN PLUG 41POS INLINE W/PINS KPSE08F20-41P-ND - CONN PLUG 41POS INLINE W/PINS KPT08E20-41P-ND - CONN PLUG 41POS INLINE RA PIN KPT08F20-41P-ND - CONN PLUG 41POS INLINE RA PIN KPT6E20-41PDN-ND - CONN PLUG 41POS INLINE PIN |
|---|
| Other Names | IKPT00E20-41SDN KPT00E2041SDN |
|---|
We can supply ITT Cannon, LLC part# KPT00E20-41SDN. Use the request quote form to request KPT00E20-41SDN pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPT00E20-41SDN. The price and lead time for KPT00E20-41SDN depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPT00E20-41SDN. We look forward to doing business with you.
