Technical Specifications of MS3108R16S-8S
| Datasheet |  MS3108R16S-8S datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | Military, MIL-DTL-5015, MS |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Female Sockets |
|---|
| Number of Positions | 5 |
|---|
| Shell Size - Insert | 16S-8 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line), Right Angle |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Threaded |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Silver |
|---|
| Features | Backshell |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | 22A |
|---|
| Voltage - Rated | 500VAC, 700VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IMS3102R16S-8P-ND - CONN RCPT 5 POS BOX MNT W/PINS IMS3102E16S-8P-ND - CONN RCPT 5 POS BOX MNT W/PINS IMS3102R16S-8PF16-ND - CONN RCPT 5 POS BOX MNT W/PINS IMS3101E16S-8P-ND - CONN RCPT 5 POS FREE HNG W/PINS IMS3101F16S-8P-ND - CONN RCPT 5 POS FREE HNG W/PINS IMS3100F16S-8P-ND - CONN RCPT 5 POS WALL MNT W/PINS IMS3100E16S-8P-ND - CONN RCPT 5 POS WALL MNT W/PINS IMS3101E16S-8PF187-ND - CONN RCPT 5 POS FREE HNG W/PINS IMS3101R16S-8P-ND - CONN RCPT 5 POS FREE HNG W/PINS IMS3100R16S-8P-ND - CONN RCPT 5 POS WALL MNT W/PINS IMS310316S-8P-ND - CONN RCPT 5 POS POTTING W/PINS |
|---|
| Other Names | IMS3108R16S-8S MS3108R16S8S |
|---|
We can supply ITT Cannon, LLC part# MS3108R16S-8S. Use the request quote form to request MS3108R16S-8S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MS3108R16S-8S. The price and lead time for MS3108R16S-8S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MS3108R16S-8S. We look forward to doing business with you.
