| Datasheet |  MS3454W16S-8S datasheet |
|---|
| Product Training Modules | Mil-DTL-5015 and AC Threaded Connectors |
|---|
| Featured Product | MIL-DTL-5015 Matrix Connectors |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | Military, MIL-DTL-5015 |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 5 |
|---|
| Shell Size - Insert | 16S-8 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Bulkhead - Front Side Nut |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Threaded |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Fluid Resistant |
|---|
| Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Silver |
|---|
| Features | - |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | 13A |
|---|
| Voltage - Rated | - |
|---|
| Operating Temperature | -55°C ~ 175°C |
|---|
| Mating Products | AMS3456W16S-8P-ND - CONN PLUG 5POS STRAIGHT W/PINS |
|---|
| Associated Product | 1591-1025-MIL - RCPT COVER SHELL SIZE 16 CADMIUM APC1369-ND - CONN CABLE CLAMP SZ 16 OLIVE APC1331-ND - CONN CABLE CLAMP SZ 16 OLIVE APC1357-ND - CONN CABLE CLAMP SZ 16 OLIVE APC1310-ND - CONN CABLE CLAMP SZ 16 OLIVE |
|---|
| Other Names | AMS3454W16S-8S MS3454W16S-8S-ND |
|---|
