Technical Specifications of MS3100R10SL-3P
| Datasheet |  MS3100R10SL-3P datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | Military, MIL-DTL-5015, MS |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 3 |
|---|
| Shell Size - Insert | 10SL-3 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Threaded |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Silver |
|---|
| Features | Backshell |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | 22A |
|---|
| Voltage - Rated | 500VAC, 700VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | 1200-1101-MIL - CONN PLUG 3 POS STRAIGHT W/SCKT 1200-1252-MIL - CONN PLUG 3 POS STRAIGHT W/SCKT 1200-1130-MIL - CONN PLUG 3 POS RT ANG W/SCKT 1200-1134-MIL - CONN PLUG 3 POS RT ANG W/SCKT IMS3106A10SL-3S-RES-ND - CONN PLUG 3 POS STRAIGHT W/SCKT IMS3106E10SL-3S-ND - CONN PLUG 3 POS STRAIGHT W/SCKT IMS3106E10SL-3SF187-ND - CONN PLUG 3 POS STRAIGHT W/SCKT IMS3106F10SL-3SF187-ND - CONN PLUG 3 POS STRAIGHT W/SCKT IMS25183-10SL-3S-ND - CONN PLUG 3 POS STRAIGHT W/SCKT IMS3108E10SL-3SF187-ND - CONN PLUG 3 POS RT ANG W/SCKT IMS3106R10SL-3SF16-ND - CONN PLUG 3 POS STRAIGHT W/SCKT |
|---|
| Other Names | IMS3100R10SL-3P MS3100R10SL3P |
|---|
We can supply ITT Cannon, LLC part# MS3100R10SL-3P. Use the request quote form to request MS3100R10SL-3P pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MS3100R10SL-3P. The price and lead time for MS3100R10SL-3P depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MS3100R10SL-3P. We look forward to doing business with you.
