| Datasheet |  RM15WTLP-12S(71) datasheet |
|---|
| Video File | Waterproof Power Connectors - Hirose |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | RM-W |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Female Sockets |
|---|
| Number of Positions | 12 |
|---|
| Shell Size - Insert | 15 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line), Right Angle |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Threaded |
|---|
| Orientation | Keyed |
|---|
| Ingress Protection | IP67 - Dust Tight, Waterproof |
|---|
| Shell Material, Finish | Zinc, Brass, Pliable PVC, Chrome or Nickel Plated |
|---|
| Contact Finish | Silver |
|---|
| Features | Backshell |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | 5A |
|---|
| Voltage - Rated | 350VAC, 490VDC |
|---|
| Operating Temperature | -25°C ~ 85°C |
|---|
| Mating Products | H124384-ND - CONN RCPT 12POS PNL MNT PIN RM15WTRZB-12P(71)-ND - CONN RCPT 12POS PNL MNT PIN RM15WTRZA-12P(71)-ND - CONN RCPT 12POS JAM NUT PIN |
|---|
| Associated Product | JR13WCC-6(72)-ND - CONN CABLE CLAMP SZ 13 M16 BLACK HR1354-ND - CONN CABLE CLAMP SZ 13 M16 BLACK HR1352-ND - CONN CABLE CLAMP SZ 13 M16 BLACK HR1356-ND - CONN CABLE CLAMP SZ 13 M16 BLACK HR1355-ND - CONN CABLE CLAMP SZ 13 M16 BLACK HR1358-ND - CONN CABLE CLAMP SZ 13 M16 BLACK H12180-ND - CONN CABLE CLAMP SZ 13 M16 BLACK H12181-ND - CONN CABLE CLAMP SZ 13 M16 BLACK HR1357-ND - CONN CABLE CLAMP SZ 13 M16 BLACK HR1804-ND - CONN CABLE CLAMP SZ15 M16 SILVER HR1353-ND - CONN CABLE CLAMP SZ 13 M16 BLACK JR13WCC-5(72)-ND - CONN CABLE CLAMP SZ 13 M16 BLACK JR13WCC-7(72)-ND - CONN CABLE CLAMP SZ 13 M16 BLACK JR13WCC-4(72)-ND - CONN CABLE CLAMP SZ 13 M16 BLACK JR13WCC-9(73)-ND - CONN CABLE CLAMP SZ 13 M16 BLACK H124099-ND - CONN CABLE CLAMP SZ 13 M16 BLACK HR1805-ND - CONN CABLE CLAMP SZ15 M16 SILVER HR1806-ND - CONN CABLE CLAMP SZ15 M16 SILVER HR1807-ND - CONN CABLE CLAMP SZ15 M16 SILVER HR1808-ND - CONN CABLE CLAMP SZ15 M16 SILVER HR1809-ND - CONN CABLE CLAMP SZ15 M16 SILVER |
|---|
| Other Names | 109-1911-9-71 |
|---|
