Technical Specifications of MKJ3A7F9-19SN
| Datasheet |  MKJ3A7F9-19SN datasheet |
|---|
| Product Photos | 155343-0001 |
|---|
| Featured Product | MKJ (Trinity) Series |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-38999, MKJ3 |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 19 |
|---|
| Shell Size - Insert | 9-19 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Bulkhead - Front Side Nut |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Nickel Plated, Electroless |
|---|
| Contact Finish | Gold |
|---|
| Features | Shielded |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 5A |
|---|
| Voltage - Rated | 500VAC |
|---|
| Operating Temperature | -55°C ~ 150°C |
|---|
| Mating Products | 1003-1416-ND - CONN PLUG 19POS STRGHT W/PINS 1003-1388-ND - CONN PLUG 19POS STRGHT W/PINS |
|---|
| Other Names | 1003-1444 155343-0001 1553430001 |
|---|
We can supply ITT Cannon, LLC part# MKJ3A7F9-19SN. Use the request quote form to request MKJ3A7F9-19SN pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MKJ3A7F9-19SN. The price and lead time for MKJ3A7F9-19SN depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MKJ3A7F9-19SN. We look forward to doing business with you.
