Technical Specifications of KPSE6E14-19PYDN
| Datasheet |  KPSE6E14-19PYDN datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Male Pins |
|---|
| Number of Positions | 19 |
|---|
| Shell Size - Insert | 14-19 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | Y |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Shrink Boot Adapter |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | KPSE02E14-19SY-ND - CONN RCPT 19POS BOX MNT SKT IKPSE00F14-19SY-ND - CONN RCPT 19POS WALL MNT W/SKTS IKPSE07E14-19SY-ND - CONN RCPT 19POS JAM NUT W/SKTS IKPT01F14-19SY-ND - CONN RCPT 19POS W/SKT INLINE IKPT07E14-19SY-ND - CONN RCPT 19POS W/SKT JAM NUT IKPSE00E14-19SY-ND - CONN RCPT 19POS WALL MNT W/SKTS KPT00F14-19SY-ND - CONN RCPT 19POS WALL MNT SKT KPT02E14-19SY-ND - CONN RCPT 19POS BOX MNT SKT |
|---|
| Other Names | IKPSE6E14-19PYDN KPSE6E1419PYDN |
|---|
We can supply ITT Cannon, LLC part# KPSE6E14-19PYDN. Use the request quote form to request KPSE6E14-19PYDN pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE6E14-19PYDN. The price and lead time for KPSE6E14-19PYDN depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE6E14-19PYDN. We look forward to doing business with you.
