Technical Specifications of KPT1E14-19PDZ
| Datasheet |  KPT1E14-19PDZ datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPT |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 19 |
|---|
| Shell Size - Insert | 14-19 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Shielded, Shrink Boot Adapter |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPSE06E14-19S23-ND - CONN PLUG 19POS W/SKT INLINE IKPT6E14-19SDZ-ND - CONN PLUG 19POS W/SKT INLINE IKPT06E14-19SDZ-ND - CONN PLUG 19POS W/SKT INLINE IKPT06F14-19SDZ-ND - CONN PLUG 19POS W/SKT INLINE IKPSE06E14-19SDZ-ND - CONN PLUG 19POS CBL MNT W/SKTS IKPSE6E14-19SDZ-ND - CONN PLUG 19POS CBL MNT W/SKTS IKPSE06F14-19SDZ-ND - CONN PLUG 19POS W/SKT INLINE |
|---|
| Other Names | KPT1E1419PDZ |
|---|
We can supply ITT Cannon, LLC part# KPT1E14-19PDZ. Use the request quote form to request KPT1E14-19PDZ pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPT1E14-19PDZ. The price and lead time for KPT1E14-19PDZ depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPT1E14-19PDZ. We look forward to doing business with you.
