Technical Specifications of KPT06B22-21S
| Datasheet |  KPT06B22-21S datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPT |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Plug, Female Sockets |
|---|
| Number of Positions | 21 |
|---|
| Shell Size - Insert | 22-21 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Solder Cup |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | - |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 13A |
|---|
| Voltage - Rated | 1000VAC, 1400VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPT02A22-21P-ND - CONN RCPT 21POS W/PIN BOX IKPT00A22-21P-ND - CONN RCPT 21POS WALL W/PIN IKPT01A22-21P-ND - CONN RCPT 21POS W/PIN INLINE KPSE00A22-21P-ND - CONN RCPT 21POS WALL MNT PIN IKPT07A22-21P-ND - CONN RCPT 21POS JAM NUT W/PIN IKPT7A22-21PEX-ND - CONN RCPT 21POS W/PIN JAM NUT IKPT00B22-21P-ND - CONN RCPT 21POS WALL W/PIN IKPT01B22-21P-ND - CONN RCPT 21POS INLINE W/PIN IKPT07A22-21PEW-ND - CONN RCPT 21POS W/PIN JAM NUT KPSE07B22-21P-ND - CONN RCPT 21POS JAM NUT W/PINS PV70W22-21P-ND - CONN RCPT 21POS WALL MNT W/PINS KPSE07A22-21P-ND - CONN RCPT 21POS JAM NUT PIN |
|---|
| Other Names | KPT06B2221S |
|---|
We can supply ITT Cannon, LLC part# KPT06B22-21S. Use the request quote form to request KPT06B22-21S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPT06B22-21S. The price and lead time for KPT06B22-21S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPT06B22-21S. We look forward to doing business with you.
