Technical Specifications of MS3120F20-41S
| Datasheet |  MS3120F20-41S datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | Military, MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 41 |
|---|
| Shell Size - Insert | 20-41 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Strain Relief |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | 1200-1044-MIL - CONN PLUG 41POS STRAIGHT W/PINS IMS3116F20-41P-ND - CONN PLUG 41POS STRAIGHT W/PINS IMS3116F20-41PF187-ND - CONN PLUG 41POS STRAIGHT W/PINS IMS3116E20-41P-ND - CONN PLUG 41POS STRAIGHT W/PINS IMS3126F20-41PF187-ND - CONN PLUG 41POS STRAIGHT W/PINS IMS3126E20-41P-ND - CONN PLUG 41POS STRAIGHT W/PINS IMS3116P20-41P-ND - CONN PLUG 41POS STRAIGHT W/PINS IMS3126P20-41P-ND - CONN PLUG 41POS STRAIGHT W/PINS IMS3116J20-41P-ND - CONN PLUG 41POS STRAIGHT W/PINS |
|---|
| Other Names | IMS3120F20-41S MS3120F20-41SPEI MS3120F20-41SPEI-ND MS3120F2041S |
|---|
We can supply ITT Cannon, LLC part# MS3120F20-41S. Use the request quote form to request MS3120F20-41S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MS3120F20-41S. The price and lead time for MS3120F20-41S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MS3120F20-41S. We look forward to doing business with you.
