Technical Specifications of CA3102E24A24PB01A176
| Datasheet |  CA3102E24A24PB01A176 datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-5015, CA-B |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Male Pins |
|---|
| Number of Positions | 12 |
|---|
| Shell Size - Insert | 24-A24 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Flange |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Reverse Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | IP67 - Dust Tight, Waterproof |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | - |
|---|
| Contact Finish Thickness | 19.7μin (0.50μm) |
|---|
| Current Rating | 41A |
|---|
| Voltage - Rated | 50V |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | CA3108F24A24S-B-F80-A176-ND - CONN PLUG 12POS RT ANG W/SKTS CA3106E24A24SB01A176-ND - CONN PLUG 12POS INLINE W/SKTS CA3106E24A24SBF80A176-ND - CONN PLUG 12POS INLINE W/SKTS ICA3108E24A24SB01A152-ND - CONN PLUG 12POS RT ANG W/SKTS |
|---|
We can supply ITT Cannon, LLC part# CA3102E24A24PB01A176. Use the request quote form to request CA3102E24A24PB01A176 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CA3102E24A24PB01A176. The price and lead time for CA3102E24A24PB01A176 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CA3102E24A24PB01A176. We look forward to doing business with you.
