Technical Specifications of M83513/13-C01CP
| Category | Connectors, Interconnects |
|---|
| Family | D-Sub Connectors |
|---|
| Manufacturer | ITT-Cannon,-LLC |
|---|
| Series | Military, MIL-DTL-83513 |
|---|
| Packaging | Bulk |
|---|
| Connector Style | D-Type, Micro-D |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 21 |
|---|
| Number of Rows | 3 |
|---|
| Shell Size, Connector Layout | 0.050 Pitch x 0.043 Row to Row |
|---|
| Contact Type | Signal |
|---|
| Mounting Type | Panel Mount, Through Hole, Right Angle |
|---|
| Flange Feature | Mating Side, Female Screwlock (2-56) |
|---|
| Termination | Solder |
|---|
| Features | - |
|---|
| Shell Material, Finish | Aluminum, Yellow Chromate Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Ingress Protection | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Voltage Rating | - |
|---|
| Current Rating | 3A |
|---|
| Housing Material | Liquid Crystal Polymer (LCP) |
|---|
| Color | - |
|---|
We can supply ITT Cannon, LLC part# M83513/13-C01CP. Use the request quote form to request M83513/13-C01CP pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number M83513/13-C01CP. The price and lead time for M83513/13-C01CP depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# M83513/13-C01CP. We look forward to doing business with you.
