FH28-40S-0.5SH(11)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | FH28-40S-0.5SH(11) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | 40 Position FFC, FPC Connector Contacts, Bottom 0.020" (0.50mm) Surface Mount, Right Angle |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| FH28-40S-0.5SH(11) Price |  |
Technical Specifications of FH28-40S-0.5SH(11)
| Datasheet |  FH28-40S-0.5SH(11) datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | FFC, FPC (Flat Flexible) Connectors |
| Manufacturer | Hirose-Electric-Co-Ltd |
| Series | FH28 |
| Packaging | Tape & Reel (TR) |
| Flat Flex Type | FFC, FPC |
| Mounting Type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Bottom |
| Number of Positions | 40 |
| Pitch | 0.020" (0.50mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.100" (2.54mm) |
| Locking Feature | Rotary Lock |
| Cable End Type | Tabbed |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Housing Material | Liquid Crystal Polymer (LCP) |
| Actuator Material | Liquid Crystal Polymer (LCP) |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Voltage Rating | 50V |
| Operating Temperature | -40°C ~ 85°C |
| Material Flammability Rating | UL94 V-0 |
| Current Rating | 0.5A |
