Technical Specifications of XF3M-6015-1B
| Datasheet |  XF3M-6015-1B datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | FFC, FPC (Flat Flexible) Connectors |
|---|
| Manufacturer | Omron-Electronics-Inc-EMC-Div |
|---|
| Series | XF3M |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Flat Flex Type | FFC, FPC |
|---|
| Mounting Type | Surface Mount, Right Angle |
|---|
| Connector/Contact Type | Contacts, Top and Bottom |
|---|
| Number of Positions | 60 |
|---|
| Pitch | 0.020" (0.50mm) |
|---|
| Termination | Solder |
|---|
| FFC, FCB Thickness | 0.30mm |
|---|
| Height Above Board | 0.079" (2.00mm) |
|---|
| Locking Feature | Rotary Lock, Backlock |
|---|
| Cable End Type | Tapered |
|---|
| Contact Material | Copper Alloy |
|---|
| Contact Finish | Gold |
|---|
| Housing Material | Liquid Crystal Polymer (LCP), Halogen Free |
|---|
| Actuator Material | Liquid Crystal Polymer (LCP), Halogen Free |
|---|
| Features | Solder Retention |
|---|
| Voltage Rating | 50V |
|---|
| Operating Temperature | -30°C ~ 85°C |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Current Rating | 0.5A |
|---|
We can supply Omron Electronics Inc-EMC Div part# XF3M-6015-1B. Use the request quote form to request XF3M-6015-1B pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number XF3M-6015-1B. The price and lead time for XF3M-6015-1B depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# XF3M-6015-1B. We look forward to doing business with you.
