Technical Specifications of ZF5S-30-01-T-WT
| Datasheet |  ZF5S-30-01-T-WT datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | FFC, FPC (Flat Flexible) Connectors |
|---|
| Manufacturer | Samtec-Inc. |
|---|
| Series | ZF5S |
|---|
| Packaging | Tube |
|---|
| Flat Flex Type | FFC |
|---|
| Mounting Type | Surface Mount, Right Angle |
|---|
| Connector/Contact Type | Contacts, Bottom |
|---|
| Number of Positions | 30 |
|---|
| Pitch | 0.020" (0.50mm) |
|---|
| Termination | Solder |
|---|
| FFC, FCB Thickness | - |
|---|
| Height Above Board | 0.079" (2.00mm) |
|---|
| Locking Feature | Slide Lock |
|---|
| Cable End Type | - |
|---|
| Contact Material | Phosphor Bronze |
|---|
| Contact Finish | Tin |
|---|
| Housing Material | Liquid Crystal Polymer (LCP) |
|---|
| Actuator Material | Liquid Crystal Polymer (LCP) |
|---|
| Features | Solder Retention, Zero Insertion Force (ZIF) |
|---|
| Voltage Rating | - |
|---|
| Operating Temperature | -55°C ~ 105°C |
|---|
| Material Flammability Rating | - |
|---|
| Current Rating | 1.4A per Contact |
|---|
We can supply Samtec Inc. part# ZF5S-30-01-T-WT. Use the request quote form to request ZF5S-30-01-T-WT pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ZF5S-30-01-T-WT. The price and lead time for ZF5S-30-01-T-WT depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ZF5S-30-01-T-WT. We look forward to doing business with you.
