FH39-61S-0.3SHW(99)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | FH39-61S-0.3SHW(99) |
|---|---|
| Manufacturer | Hirose Electric Co Ltd |
| Description | 61 Position FPC Connector Contacts, Top and Bottom 0.012" (0.30mm) Surface Mount, Right Angle |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| FH39-61S-0.3SHW(99) Price |  |
Technical Specifications of FH39-61S-0.3SHW(99)
| Category | Connectors, Interconnects |
|---|---|
| Family | FFC, FPC (Flat Flexible) Connectors |
| Manufacturer | Hirose-Electric-Co-Ltd |
| Series | FH39 |
| Packaging | Tape & Reel (TR) |
| Flat Flex Type | FPC |
| Mounting Type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Top and Bottom |
| Number of Positions | 61 |
| Pitch | 0.012" (0.30mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.20mm |
| Height Above Board | 0.044" (1.10mm) |
| Locking Feature | Flip Lock, Backlock |
| Cable End Type | Tapered |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Housing Material | Liquid Crystal Polymer (LCP) |
| Actuator Material | Polyamide (PA), Nylon |
| Features | Zero Insertion Force (ZIF) |
| Voltage Rating | 30V |
| Operating Temperature | -55°C ~ 85°C |
| Material Flammability Rating | UL94 V-0 |
| Current Rating | 0.2A |
