Technical Specifications of FA1005SA1-R8000
| Datasheet |  FA1005SA1-R8000 datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | FFC, FPC (Flat Flexible) Connectors |
|---|
| Manufacturer | JAE-Electronics |
|---|
| Series | FA10 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Flat Flex Type | FPC |
|---|
| Mounting Type | Surface Mount, Right Angle |
|---|
| Connector/Contact Type | Contacts, Top and Bottom |
|---|
| Number of Positions | 5 |
|---|
| Pitch | 0.020" (0.50mm) |
|---|
| Termination | Solder |
|---|
| FFC, FCB Thickness | 0.20mm |
|---|
| Height Above Board | 0.036" (0.90mm) |
|---|
| Locking Feature | - |
|---|
| Cable End Type | Tabbed |
|---|
| Contact Material | Copper Alloy |
|---|
| Contact Finish | Gold |
|---|
| Housing Material | Plastic |
|---|
| Actuator Material | Plastic |
|---|
| Features | Low Insertion Force (LIF) |
|---|
| Voltage Rating | 50V |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Current Rating | 0.5A per Contact |
|---|
We can supply JAE Electronics part# FA1005SA1-R8000. Use the request quote form to request FA1005SA1-R8000 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FA1005SA1-R8000. The price and lead time for FA1005SA1-R8000 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FA1005SA1-R8000. We look forward to doing business with you.
