Technical Specifications of 09FMN-SMT-A-TF
| Datasheet |  09FMN-SMT-A-TF datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | FFC, FPC (Flat Flexible) Connectors |
|---|
| Manufacturer | JST-Sales-America-Inc. |
|---|
| Series | FMN |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Flat Flex Type | FFC |
|---|
| Mounting Type | Surface Mount, Right Angle |
|---|
| Connector/Contact Type | Contacts, Top |
|---|
| Number of Positions | 9 |
|---|
| Pitch | 0.039" (1.00mm) |
|---|
| Termination | Solder |
|---|
| FFC, FCB Thickness | 0.30mm |
|---|
| Height Above Board | 0.118" (3.00mm) |
|---|
| Locking Feature | - |
|---|
| Cable End Type | Straight |
|---|
| Contact Material | Phosphor Bronze |
|---|
| Contact Finish | Tin |
|---|
| Housing Material | Polyamide (PA6T), Nylon 6T |
|---|
| Actuator Material | - |
|---|
| Features | Low Insertion Force (LIF) |
|---|
| Voltage Rating | 50V |
|---|
| Operating Temperature | -25°C ~ 85°C |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Current Rating | 0.5A |
|---|
We can supply JST Sales America Inc. part# 09FMN-SMT-A-TF. Use the request quote form to request 09FMN-SMT-A-TF pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 09FMN-SMT-A-TF. The price and lead time for 09FMN-SMT-A-TF depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 09FMN-SMT-A-TF. We look forward to doing business with you.
