Technical Specifications of SFW20R-2STGE5LF
| Datasheet |  SFW20R-2STGE5LF datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | FFC, FPC (Flat Flexible) Connectors |
|---|
| Manufacturer | Amphenol-FCI |
|---|
| Series | SFW-R |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Flat Flex Type | FPC |
|---|
| Mounting Type | Surface Mount, Right Angle |
|---|
| Connector/Contact Type | Contacts, Top |
|---|
| Number of Positions | 20 |
|---|
| Pitch | 0.039" (1.00mm) |
|---|
| Termination | Solder |
|---|
| FFC, FCB Thickness | 0.33mm |
|---|
| Height Above Board | 0.106" (2.70mm) |
|---|
| Locking Feature | Slide Lock |
|---|
| Cable End Type | Tapered |
|---|
| Contact Material | Phosphor Bronze |
|---|
| Contact Finish | Gold |
|---|
| Housing Material | Polyphenylene Sulfide (PPS), Glass Filled |
|---|
| Actuator Material | Polyphenylene Sulfide (PPS), Glass Filled |
|---|
| Features | Zero Insertion Force (ZIF) |
|---|
| Voltage Rating | 100V |
|---|
| Operating Temperature | -55°C ~ 105°C |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Current Rating | 1A |
|---|
We can supply Amphenol FCI part# SFW20R-2STGE5LF. Use the request quote form to request SFW20R-2STGE5LF pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SFW20R-2STGE5LF. The price and lead time for SFW20R-2STGE5LF depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SFW20R-2STGE5LF. We look forward to doing business with you.
