FB10S031JA2R6000
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | FB10S031JA2R6000 |
|---|---|
| Manufacturer | JAE Electronics |
| Description | 31 Position FPC Connector Contacts, Bottom 0.012" (0.30mm) Surface Mount, Right Angle |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| FB10S031JA2R6000 Price |  |
Technical Specifications of FB10S031JA2R6000
| Datasheet |  FB10S031JA2R6000 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | FFC, FPC (Flat Flexible) Connectors |
| Manufacturer | JAE-Electronics |
| Series | FB10 |
| Packaging | Tape & Reel (TR) |
| Flat Flex Type | FPC |
| Mounting Type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Bottom |
| Number of Positions | 31 |
| Pitch | 0.012" (0.30mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.20mm |
| Height Above Board | 0.036" (0.90mm) |
| Locking Feature | Flip Lock |
| Cable End Type | Tabbed or Tapered |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Housing Material | Plastic |
| Actuator Material | Plastic |
| Features | Zero Insertion Force (ZIF) |
| Voltage Rating | 50V |
| Operating Temperature | -40°C ~ 85°C |
| Material Flammability Rating | - |
| Current Rating | 0.35A |
