SFV26R-2STBE5HLF
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | SFV26R-2STBE5HLF |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | 26 Position FFC, FPC Connector Contacts, Top 0.020" (0.50mm) Surface Mount, Right Angle |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| SFV26R-2STBE5HLF Price |  |
Technical Specifications of SFV26R-2STBE5HLF
| Datasheet |  SFV26R-2STBE5HLF datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | FFC, FPC (Flat Flexible) Connectors |
| Manufacturer | Amphenol-FCI |
| Series | SFV-R |
| Packaging | Tape & Reel (TR) |
| Flat Flex Type | FFC, FPC |
| Mounting Type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Top |
| Number of Positions | 26 |
| Pitch | 0.020" (0.50mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.30mm, 0.33mm |
| Height Above Board | 0.071" (1.80mm) |
| Locking Feature | Slide Lock |
| Cable End Type | Straight, Tapered |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Housing Material | Liquid Crystal Polymer (LCP), Glass Filled, Halogen Free |
| Actuator Material | Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Voltage Rating | 50V |
| Operating Temperature | -55°C ~ 105°C |
| Material Flammability Rating | UL94 V-0 |
| Current Rating | 0.5A |
