ZF1-20-02-T-WT-TR
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ZF1-20-02-T-WT-TR |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | 20 Position FFC Connector Contacts, Top 0.039" (1.00mm) Surface Mount, Right Angle |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ZF1-20-02-T-WT-TR Price |  |
Technical Specifications of ZF1-20-02-T-WT-TR
| Category | Connectors, Interconnects |
|---|---|
| Family | FFC, FPC (Flat Flexible) Connectors |
| Manufacturer | Samtec-Inc. |
| Series | ZF1 |
| Packaging | Tape & Reel (TR) |
| Flat Flex Type | FFC |
| Mounting Type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Top |
| Number of Positions | 20 |
| Pitch | 0.039" (1.00mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.118" (3.00mm) |
| Locking Feature | Slide Lock |
| Cable End Type | Straight |
| Contact Material | Phosphor Bronze |
| Contact Finish | Tin |
| Housing Material | Liquid Crystal Polymer (LCP) |
| Actuator Material | Polyphenylene Sulfide (PPS) |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Voltage Rating | - |
| Operating Temperature | -55°C ~ 105°C |
| Material Flammability Rating | UL94 V-2 |
| Current Rating | 1.9A per Contact |
