B78477P1010A344
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | B78477P1010A344 |
|---|---|
| Manufacturer | EPCOS (TDK) |
| Description | 4 Port RJ45 Magjack Connector Through Hole 10/100 Base-T, AutoMDIX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| B78477P1010A344 Price |  |
Technical Specifications of B78477P1010A344
| Datasheet |  B78477P1010A344 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | EPCOS-(TDK) |
| Series | B78477P |
| Packaging | Tray |
| Connector Type | RJ45 |
| Number of Ports | 4 |
| Number of Rows | 1 |
| Applications | 10/100 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.541" (13.75mm) |
| LED Color | Green - Yellow |
| Number of Cores per Jack | 4 |
| Shielding | Shielded, EMI Finger |
| Features | Board Guide |
| Tab Direction | Down |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Contact Finish Thickness | 15μin (0.38μm) |
| Shield Material | Copper Alloy |
| Housing Material | Thermoplastic |
| Operating Temperature | 0°C ~ 70°C |
